40kw 50kva YC4D60-D21 YUCHAI Diesel Generator Set

40kw 50kva YC4D60-D21 YUCHAI Diesel Generator Set

Marka Adı:	Yuchai
Model Numarası:	YC4D60-D21
Moq:	1 adet
fiyat:	Price:Negotiable
Ödeme Şartları:	Western Union, T/T, D/P, L/C
Tedarik Yeteneği:	200pcs/ay

Ayrıntılı Bilgiler

Ürün Tanımı

Ayrıntılı Bilgiler

Menşe yeri:

Sertifika:

ISO 9001:14000,CE,EACC

Marka Adı::

40KW Yuchai dizel jeneratörü

Nominal Voltaj::

230V/400V

Motor Modeli::

Yuchai YC4D60-D21

Değerlendirilmiş Akım::

Sıklık::

50Hz/60Hz

Alternatör::

MBC22B

Kontrol Paneli::

Deepsea / Harsen / SmartGen

Sertifika::

ISO 9001: 14000, CE

ATS::

İsteğe bağlı

Teslimat::

7-30 gün

Garanti Süresi::

1 yıl

Jin seti boyutu::

1800*700*1150mm

Jeneze Ağırlığı::

800kg

Hız::

1500rpm/1800rpm

Model Numarası::

MB-40

Ambalaj bilgileri:

Tüketici gereksinimleri olarak ahşap taşıyıcılara sarılmış plastik. LCL, 20ft ve 40ft mevcuttur.

Yetenek temini:

200pcs/ay

Ürün Tanımı

Yuchai Diesel Generator Sets Description:

40kw rainproof electric generator

With YUCHAI engine YC4D60-D21

Less diesel consumption

Turbocharge aspiration

Reasonable and reliable emergency power generation

Warranty 12 months or 1000 hours warranty time

40kw 50kva YC4D60-D21 YUCHAI Diesel Generator Set 0

Manufacturer		Changsha Mingbang Intelligent Technology Co.Ltd
Model		MB-40
Prime Powder		80KW/100KVA
Standby Powder		95KW/118.75KVA
Power Factor		COSΦ=0.8(lagging)
Max. Output current		72A
Genset Weight		800kg(Net)
Length x Width x Height (Engine) (mm)		18007001150
Voltage		400/230V
Frequency		50HZ
Yuchai Engine Specification
Manufacturer		Guangxi Yuchai Machinery Group Co., Ltd
Model		YC4D60-D21
Rated speed		1500rpm
Prime Powder		40KW/50KVA
Standby Powder		44KW/55KVA
Fuel Consumption		<=240g/KW.H
Lube oil capacity		9-11L
Bore (mm) x Stroke (mm)		108*115mm
Compression ratio		17.5:1
Displacement (litre)		4.214
Coolant capacity, L		/
Configuration		4 in line ,four-stroke, Turbocharged, Charge Air Cooled
Cooling		Liquid Cooled
Governor type		Electronic
Starting voltage		24 Volts DC
Filtration system		Air Filter/Fuel Filter/Oil Filter
Alternator Specification
Manufacturer		Changsha Mingbang Intelligent Technology Co.Ltd
Model		MBC22B
Voltage Regulator		AVR
Voltage adjust range		±1%
Rated Voltage/Frequency/Factor		400/230V, 50HZ, COSΦ 0.8(lagging) ,Three-phase Four-wire
Steady-state Frequency		5%
No-load Voltage Adjust Range		>=95%-105%
Insulation Class		H
IP Protection		22
Excitation Type		Blushless

40kw 50kva YC4D60-D21 YUCHAI Diesel Generator Set 1

About MingBang Intelligent Technology

40kw 50kva YC4D60-D21 YUCHAI Diesel Generator Set 3

Mingbang Intelligent Technology Co.,LTD was established in 2005,occupies an area of 5042 square meters,located in Yangzhou city,Jiangsu Province,which is the central part of manufacturing industry zone in Southeast China near Shanghai

Mingbang works closely with all large power manufactures such as Cummins, Perkins, Deutz,
Volvoand Chinese local brands SDEC,Yuchai,Jichai diesel generator sets,engines with
Stamford,Marathom,Leroy-Somer,and MBKL manufactured alternators ,and so on. Key diesel
generator stock ranges from 10KVA to 3000 KVA, classifying silent generator, open generator ,
container generator, mobile genset, and so on.
Whether you require support for an office, residential development ,industrial development or
shopping centre, hospital,railways,prison, hotal, airport ,bank data centre, Mingbang will
support you the most reliable and most cost-efficient generators and accessories.
Weclome to visit our factory!

Our customers

Yuchai Diesel Electric Generator Set AC Three Phase 40kw 50kva YUCHAI Small Rainproof Electric Generator

Free loading capacity analysis
Free technology consulations
Free testing and debuging
12months or 1000hours warranty service
Spare parts offered
OEM service buyer label offered
24/7 on-line technical service

More details for diesel generator sets ,please contact us any time

Your further inquiry will be welcome!!
